INTRODUCING

INTRODUCING

Revolutionizing Crop Protection

The World’s Most Productive
Autonomous Spray Aircraft

Pelican 2 is a next-generation autonomous electric crop protection UAS. The aircraft combines unmatched productivity and precision to deliver lower direct operating costs than any other aerial application solution on the market.

starting at

USD 550,000

FEATURES

Next-Generation Aircraft

Innovation Driven by Experience

300 L Payload, 18 M Swath

Direct Operating Costs as low as 1.00 USD per hectare

Intuitive, low-risk operation

Autonomous Night Spray

Extend your spray window, target
pests during optimal conditions.

Autonomous Night Spray

Extend your spray window, target
pests during optimal conditions.

SPRAY PERFORMANCE

Autonomous Aerial Application

Industry-leading Spray Performance

121 ha/hr work rate @ 5 L/ha application rate
90 ha/hr work rate @ 10 L/ha application rate
70 ha/hr work rate @ 20 L/ha application rate

Select multiple boom configurations, including hydraulic nozzles or proprietary electric rotary atomizers. When equipped with atomizers, Pelican dynamically adjusts droplet size in flight to maximize chemical efficiency and minimize drift.

Pelican application efficiency: 96%
Turboprop application efficiency: 88%
Source: US -EPA AgDRIFT® model

Built for Agriculture

Pyka’s Proprietary Spray System

Welded Extruded Aluminum Spray Boom

Exceedingly robust with flex-link to fuselage.

Nozzles
‍‍

Ceramic hollow cone nozzles support a wide range of flow rates and droplet sizes.

Rotary Atomizers
‍

Pyka proprietary variable speed electric rotary atomizers - wide droplet range (60 - 400 micron VMD), and ultra-narrow droplet spectrum.Patented in-flight speed control based on release height

Quick Connects on all Hardware
‍

Remove critical components in under five minutes.

Electric Agitation System
‍
‍

Aggressive mechanical agitation keeps challenging insoluble chemicals and oils in suspicion, even while the aircraft is on the ground.

High-speed Brushless CentrifugalPump with Silicon Carbide Seal

Low maintenance, high power pump with digital flow control and near-instantaneous on/off.

SPRAY SYSTEM

SPRAY QUALITY

Elevating Agriculture

Best-in-Class Spray Quality

Supports multiple flowrates and droplet sizes

5L/ha, 10L/ha, 15L/ha, 20L/ha
150 - 250 micron droplet size

Crop type: Corn
Location: Brazil
Pest: Fungus, Insect
Date: 2023
Trial outcome: Equal to or better than Turboprop

Crop type: Banana
Location: Honduras
Pest: Fungus
Date: 2024
Trial outcome: Equal to or better than Turboprop

Elevating Agriculture

Battery System

• 100V, 6kWh, 65 lbs each
‍• Hot swappable
‍• 3-year, 1000 cycle warranty

• Charge, store, and cool 12 batteries simultaneously
• Continuous operation in high temperature and humid environments
• Touchscreen interface

Battery System FAQ

How long can the plane fly per charge?

Two flights with reserve, or approximately 30
minutes of flight time.

How many sets of batteries come with the airplane?

We ship each aircraft with five sets of
batteries.

How long does a set of batteries take to
charge?

Two Hours

Do I need to wait for batteries to charge or cool?

No, with five sets of batteries you can operate 24/7without breaks to cool or charge.

How long will a battery last?

The batteries are warrantied for 3-years or 1,000cycles (3-years of use at 1,000 hours/year)

The cells have been tested to 1,800 cycles

What power do I need for the charger?

The charge cart requires 150 amps at 220V, single phase.

BATTERY SYSTEM

Technical

Specifications

Propulsion System

‍Motors

Four (4) electric motors

Power

‍100 kW combined

Propellor

Composite, fixed pitch

Battery

‍18 kWh lithium ion

Dimensions

Wing span

11.5 m / 38 ft

‍Length

6.0 m / 20 ft

Swath Width

18 m / 59 ft

Weights

Empty Weight
with swappable battery

316 kg / 700 lbs

Payload

281 kg / 620 lbs , 281 l / 74 gal

Gross Weight

599 kg / 1,320 lbs

Performance

‍Stall with flaps

35 knots

Application speed

60-70 knots

Take off run

180 m / 600 ft with max payload

Runway requirement

250 m x 8 m / 820 ft x 26 ft

Endurance

35 mins (+10 min reserve)

Work rate
@18 m (59 ft) swath width

90 hectares/hour (222 acres/hour) at 10 L/ha
70 hectares/hour (173 acres/hour) at 20 L/ha
